Product details & parameters

Extend the life of the bearing: the internal oil inlet and oil outlet pressure chambers are completely opposite, the result is that the radial load caused by the pressure is balanced, and the bearing only bears external load;

Extended product life: The excellent design of these pumps makes them last longer, and they have been proven to work in harsh environments;

Strong adaptability: The characteristics of large flow, high pressure and high speed enable these pumps to meet the needs of many types of modern mechanical equipment hydraulic circuits;

Good performance: low blade tip/stator load allows high pressure operation, because the oil inlet path is designed to accelerate the oil evenly, so high rotational speed is possible, and the filling characteristics are good, especially at low inlet pressure.

Low cost: The efficient design of the V series produces an extremely high efficiency/pump investment ratio, and its use in the industrial field results in an extremely low pump cost/power ratio.

Installation and use

1. During installation, the coaxiality error between the pump shaft and the drive motor shaft should be <0.10mm (total reading difference of the dial gauge), the maximum allowable angle error should be <0.2°, and a flexible coupling should be used. The pump shaft should not bear radial and axial loads; the support structure should be firm, rigid, and able to fully absorb vibration.

2. Suction pressure at the pump suction port: the recommended inlet pressure is 0~+35KPa.

3. Keep the oil clean, the pipeline and oil tank must be thoroughly cleaned; the oil accuracy level should be within NSA12 level.

4. The normal operation of the pump (under rated conditions) is based on the use of SAE10W oil in the range of 38℃ to 82℃ (or corresponding viscosity).

5. Before starting the pump, check whether the inlet and outlet oil ports and the direction of rotation are correct; after the entire pump is installed, turn the pump shaft by hand, which should be uniform and flexible. At the first start, if the pump is not oiled immediately, the air should be discharged from the oil outlet pipe of the pump.

6. When the pump is put into use for the first time, the pump body and the oil suction pipe should be filled with oil. Never allow the pump to run without oil.

7. Do not start the pump when the outlet pressure is lower than the inlet pressure, which will cause working noise and blade instability.

8. Cold start condition: When using SAE10W oil in the range of 860~40cSt, the speed and pressure should be limited to 50% of their respective ratings until the system is warmed up. When the oil viscosity exceeds 860cSt, special attention should be paid when starting to warm up the entire system, including the remote cylinder and motor.

9. When running at high temperature, the viscosity must not be lower than 13cSt and the temperature must not exceed 99℃, because the expected life of the pump core components and seals will be shortened.

Company profile & advantages

1.The company established more than 10 years, old brand, worthy of trust,Has more than 1000k+ followers

2.The company's product category is complete, also have a variety of accessories to provide.

3.All products have been passed strict quality test before shipment, make sure high quality.

4.24H customer service,Please feel free to contact me if you have any questions.

5.One-year warranty, we have professional and technical personnel for docking, product quality is hard, and after-sales are guaranteed. After the one-year warranty is over, we can provide maintenance services for customers (this requires a fee).

Guangdong Yihe Hydraulic Technology Co., Ltd.

We are Guangzhou Yisheng Machinery Equipment Co.,Ltd., which located in Foshan City, Guangdong Province, China. We have R&D department with about 5-10 engineers and designers. Our factory have over 100 skilled employees, our production facility have many advanced manufacturing equipments and testing equipments, such as numerical control lathe, the processing center, CNC milling machine, special CNC grinding machine, double grinding machine, automatic 3D measuring instrument, etc..

Our main products are hydraulic variable displacement vane pump, double pump, HVP high pressure variable displacement vane pump, PV2R1 & PV2R2 series,V&VQ series,T6&T7 series, SQP series and VQ series of fixed displacement vane pump and electrical motors for hydraulic application.

Our products are widely used for industrial machinery, NC lathe machine, shoe machinery, wood working machines, plastic machines, construction machines and various hydraulic system machinery. We also able to supply the customized products and services as per your spec. ,we are looking forward to cooperating with your company sincerely.
